Kabby Flanges is a reputable manufacturer and supplier located in Abuja, Nigeria, specializing in high-quality DIN 2527 PN6 Blind Flanges. These flanges are expertly designed to ensure a secure, leak-proof seal for piping systems, which is essential for safe operation and maintenance. At Kabby Flanges, they utilize cutting-edge manufacturing techniques, rigorous quality control, and top-notch material sourcing to produce DIN 2527 PN6 Blind Flanges that comply with international standards. These flanges find their place in various industries, including oil and gas, chemical processing, water treatment, and power generation, where dependable and durable flange connections are vital for maintaining safety and efficiency.
The DIN 2527 PN6 Blind Flanges are crafted from high-grade carbon steel, stainless steel, or alloy steel, providing outstanding mechanical properties such as high tensile and yield strength, hardness, and toughness. Built to endure moderate pressure and temperature, these flanges deliver reliable performance across different industrial settings. Their sturdy design ensures complete closure of pipelines, effectively preventing leaks and allowing for easy inspection, maintenance, and modifications without sacrificing safety.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| D | b | k | Number | Thread | d2 | Shape B | |
| Kg | |||||||
| 15 | 80 | 12 | 55 | 4 | M 10 | 11 | 0.44 |
| 20 | 90 | 14 | 65 | 0.66 | |||
| 25 | 100 | 14 | 75 | 0.83 | |||
| 32 | 120 | 14 | 90 | M 12 | 14 | 1.18 | |
| 40 | 130 | 14 | 100 | 1.39 | |||
| 50 | 140 | 14 | 110 | 1.63 | |||
| 65 | 160 | 14 | 130 | 2.15 | |||
| 80 | 190 | 16 | 150 | M 16 | 18 | 3.44 | |
| 100 | 210 | 16 | 170 | 4.22 | |||
| 125 | 240 | 18 | 200 | 8 | 6.11 | ||
| 150 | 265 | 18 | 225 | 7.51 | |||
| 200 | 320 | 20 | 280 | 12.31 | |||
| 250 | 375 | 22 | 335 | 12 | 18.54 | ||
| 300 | 440 | 22 | 395 | M 20 | 22 | 25.46 | |
| 350 | 490 | 22 | 445 | 31.77 | |||
| 400 | 540 | 22 | 495 | 16 | 38.49 | ||
| 500 | 645 | 24 | 600 | 20 | 60.10 | ||
Kabby Flanges, a leading supplier in Abuja, Nigeria, offers an extensive selection of DIN 2527 PN6 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2527 PN6 Blind Flanges are primarily used to seal the ends of pipes, valves, or pressure vessels in low-pressure systems. They are widely used in industries such as oil and gas, water treatment, chemical processing, and petrochemicals. These flanges help close off unused or maintenance openings in pipelines and equipment, preventing leakage and ensuring system integrity. Their durable construction and secure sealing capability make them ideal for applications where pressure and temperature fluctuations are minimal, providing a reliable and cost-effective solution for system maintenance and isolation.
Yes, we offer custom sizes for DIN 2527 PN6 Blind Flanges to meet specific project needs. Our team at Kabby Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@kabbyflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2527 PN6 BLRF Flanges Supplier in Abuja | Alloy Steel DIN 2527 PN6 Blind Flanges Manufacturer in Nigeria |
| DIN 2527 PN6 Blind Flange Dimensions | Raised Face DIN 2527 PN6 Blind Flange Manufacturer |
| 18 inch DIN 2527 PN6 Carbon Steel Blind Flange | DIN 2527 PN6 Blind Flange Dimensions in mm |
| Stainless Steel DIN 2527 PN6 Blind Flange | ASTM B564 Raised Faced DIN 2527 PN6 Blind Flanges |
| DIN 2527 PN6 Blind FF Flange Supplier | Suppliers of DIN 2527 PN6 Blind Flange |
| Alloy Steel DIN 2527 PN6 Blind Flanges | Copper Nickel DIN 2527 PN6 Blind Flanges at Best Price |
| 8 Inch DIN 2527 PN6 Blind Pipe Flanges | DIN 2527 PN6 Blind Flanges Stockist |
| DIN 2527 PN6 BLRF Flange Stockist in Nigeria | Raised Faced DIN 2527 PN6 Slip-On flanges Dealer in Nigeria |
| Nickel Alloy DIN 2527 PN6 Blind Flange | Mild Steel DIN 2527 PN6 Blind Flange |
| DIN 2527 PN6 BLRF Flange Exporter | DIN 2527 PN6 Blind Flange Pressure Ratings |
| Raised Face DIN 2527 PN6 Blind Plate Flanges | Titanium DIN 2527 PN6 Blind Flanges |
| 30 inch DIN 2527 PN6 Blind Flange Dealer | Raised Face DIN 2527 PN6 Blind Flanges Manufacturer |
| DIN 2527 PN6 Large Diameter Blind Flange | 30 Inch DIN 2527 PN6 Blind Pipe Flange Dimensions |
| 4 inch Stainless Steel DIN 2527 PN6 Blind Flange | DIN 2527 PN6 Blind RF Flanges Stockholder |
| DIN 2527 PN6 Blind Flanges Supplier in Ibadan | MS DIN 2527 PN6 Blind Flange |
| Carbon Steel Raised Face DIN 2527 PN6 Blind Flange Stockist | Duplex Steel DIN 2527 PN6 BLRF Flanges Supplier in Kano |
| DIN 2527 PN6 Blind Pipe Flanges Wholesaler | DIN 2527 PN6 BLRF Flanges Supplier |
| DIN 2527 PN6 Blind Flange Manufacturer | Flat Face DIN 2527 PN6 Blind Flange Manufacturer |
| DIN 2527 PN6 BLRF Flanges Distributor in Nigeria | Flat Face DIN 2527 PN6 Blind Flanges Exporter |
| German Standard DIN 2527 PN6 Blind Flanges | DIN 2527 PN6 Blind Flange Supplier in Nigeria |
| ASME SA105N Raised Faced DIN 2527 PN6 Blind Flanges | 18 inch Carbon Steel DIN 2527 PN6 Blind Flange |
| DIN 2527 PN6 Blind Pipe Flanges Supplier in Lagos | Duplex Steel DIN 2527 PN6 Blind Flanges |
| Carbon Steel DIN 2527 PN6 Blind Flange | DIN 2527 PN6 Blind RF Flange Supplier |
You’ll often find DIN 2527 PN6 Blind Flanges in pipelines, pressure vessels, pumps, and valves where a system needs to be terminated or temporarily closed. They are particularly suited for low-pressure applications in oil and gas pipelines, chemical plants, water treatment facilities, and power generation systems. These flanges offer durable, secure, and efficient connections, guaranteeing operational safety and reliability across a wide range of industrial sectors.
